Industrial 1300x2500mm laser marking system for smart mirrors & elevator plates. Seamless splicing, 7000mm/s speed. Inquire now for a custom solution!
1. Large-Format Seamless Splicing Technology
Unlimited Creativity: Unlike standard marking machines limited to small areas, the FDF-1325 supports seamless splicing marking. It can process large-scale patterns on elevator background plates and oversized mirrors without visible joints.
Customizable Working Area: While 1300x2500mm is standard, we offer fully customizable sizes up to 2000x4000mm to meet your specific industrial requirements.
2. Professional SYNTEC Control System (CNC Grade)
High Stability: Equipped with the high-end SYNTEC (Taiwan) control and motion system, ensuring industrial-grade stability during complex, high-speed operations.
CNC Support: Fully supports CNC integration, allowing for precise control of intricate patterns and professional-grade workflow management.
3. Eco-Friendly Alternative to Traditional Etching
Green Technology: A perfect replacement for traditional chemical corrosion (acid etching) processes. No hazardous waste, no pollution—just clean, high-speed laser marking that reduces production costs and environmental impact.
Precision Output: Achieve fine lines down to 0.1mm and characters as small as 0.2mm, providing a level of detail that chemical etching cannot match.
4. Specialized for Smart Mirrors & Decorative Metal
Industry Expert: Ideally designed for the Smart Mirror (Bathroom) industry for high-speed paint removal, and the Elevator industry for marking decorative patterns on stainless steel panels.
Multi-Material Versatility: Highly effective on stainless steel, aluminum, mirrors (sandblasting effect), wood, and even acrylic and leather.
5. High-Speed Scanning with Premium Optics
7000mm/s Speed: Features high-speed digital galvanometers and high-transmittance field lenses, delivering marking speeds up to 7000mm/s for maximum throughput.
Top-Brand Laser Sources: Compatible with world-class laser sources including JPT, Raycus, or IPG (Fiber/UV/CO2/Green), ensuring a lifespan of up to 100,000 hours.
6. Industrial-Grade Build Quality
950KG Heavy-Duty Chassis: The machine features a thickened sheet metal frame weighing 950kg, ensuring zero vibration during high-speed marking and maintaining a positioning accuracy of 0.05mm over years of heavy use.
Machine Model: |
FDF-1325 |
Laser Power: |
10W/20W/30W/50W/60/100W/200W |
Applicable Materials: |
Metal, stone, wood, mirror |
Laser Wavelength: |
1064/355/10.6/532 |
Work Area： |
1200 * 1200mm-2000 * 4000mm can be customized to any size |
working environment: |
Temperature 10-35 ℃, humidity 5-85% |
carving speed: |
≤7000mm/s |
Carving depth: |
≤0.2mm |
Minimum line width: |
0.1mm |
Positioning accuracy: |
0.05mm |
Minimum character: |
0.2mm |
Support graphic and textual formats: |
PLT\AI\DXF\BMP.... |
Does it support CNC: |
yes |
Machine weight: |
950KG |
Cooling method: |
air-cooled/water-cooled |
1、This product comes with a one-year warranty from the date of purchase (excluding consumables). Optical lenses and laser tubes are consumables, with a three-month warranty。
2、During the warranty period, if there is a malfunction in the normal use of our company's products, you can enjoy our company's free warranty service by presenting the warranty card or invoice in accordance with the contents of this warranty clause.
Q: What customized services you provided?
A: Founder Laser is the true manufacturer, we have own factory, therefore we could supply full OEM and ODM service.
Q: What payment method you accept?
A: On Alibaba, we supply Trade Assurance Order, and VIA this method, you could pay by T/T, L/C, Credit Card, etc.
Q: What shipping methods you provide?
A: We give customer EXW, FOB, CFR, DDP, DDU, and any ways you want.
Q: How long is the delivery time?
A: About the production time, it depend on the machine mode you require and which country you from. About the shipping time, it
depend on the chosen transportation method.
Q: I don’t know how to use after i receive or i have problem during use, how to do?
A: We can provide team viewer/Whatsapp/Email/Phone/Skype with cam till all of your problems finished. We can also provide Door
Service if you need.
Q: I don’t know which one is suitable for me ?
A: Just tell us below information:
1) Max work size: choose most suitable model.
2) Materials and cutting thickness: power of laser generator.
3) Business industries: We sell a lot and give advice on this business line
